Instrument Installation Systems for Industrial Manufacturing
Snap Track cable tray, instrument stands, and modular racks for chemical manufacturing, food and beverage processing, pharmaceutical facilities, and OEM equipment packages.
THE INDUSTRIAL MANUFACTURING ENVIRONMENT
Diverse process requirements and facility-wide instrumentation standards.
Industrial manufacturing encompasses a broad range of process environments — chemical manufacturing, food and beverage processing, pharmaceutical production, pulp and paper, metals processing, and OEM equipment packages for virtually every manufacturing sector. Each segment has its own process conditions, regulatory requirements, and instrumentation standards. What they share is the need for organized, maintainable, code-compliant cable management and instrument support hardware that performs reliably in working industrial environments.
Unlike the oil and gas sector where classified area requirements and petrochemical exposure dominate specification decisions, industrial manufacturing facilities present a wider range of process conditions that require more nuanced cable management and instrument support selection. A pharmaceutical cleanroom has fundamentally different requirements than a chemical plant — both are industrial manufacturing, but the specifications diverge significantly.
TechLine Mfg. products are installed across the full spectrum of industrial manufacturing environments. The product range — from marine-grade aluminum Snap Track for corrosive process areas to standard galvanized channel for light-duty applications — covers the requirements of industrial manufacturing without over-specifying for environments that don't need process plant-grade hardware.
CABLE ROUTING IN MANUFACTURING FACILITIES
Channel tray as the conduit alternative in manufacturing environments.
Industrial manufacturing facilities have historically used rigid conduit for instrument and control cable routing because the electricians building the facilities were trained in conduit and because the alternative — cable tray — was associated with large industrial projects that seemed out of scale for a manufacturing plant.
That perception is changing. The cost advantage of channel cable tray over conduit — 50% or more in total installed cost on comparable runs — applies equally in manufacturing facilities as in refineries. The labor savings, the reconfigurability, and the maintenance access advantages of an open tray system matter as much on a manufacturing plant floor as on a process plant pipe rack.
Where Snap Track is specified in manufacturing facilities:
OEM equipment packages
Skids, modular process units, and packaged systems are one of the highest-value applications for Snap Track in manufacturing. Equipment skid builders specify Snap Track because the push-pin assembly is fast, the 20-foot extruded sections minimize joints on long skid runs, and the system presents a clean, professional appearance that reflects well on the finished package. Field training takes under an hour, and the installation is consistent regardless of which crew is working.
Retrofit and expansion projects
Manufacturing plant retrofit and expansion projects are a natural Snap Track application. Adding cable capacity to an existing conduit system requires new conduit runs, new pull boxes, and significant labor. Adding cables to an existing Snap Track run requires snapping in additional tray sections and laying in the cables. In a manufacturing environment where the production process evolves continuously, this reconfigurability has real operational value.
Food, beverage, and pharmaceutical applications
Where hygienic cable management matters, Snap Track's solid aluminum side rails prevent debris accumulation and are easier to clean than open wire basket. In cleanroom and food-grade environments, cable management that doesn't trap particulates and can be wiped down during cleaning cycles reduces the contamination risk that open wire basket creates.
FIELD DEVICE MOUNTING
Instrument stands and equipment mounting for manufacturing applications.
Manufacturing facility instrument mounting is more varied than process plant applications. Single instruments on process lines use standard pipe mount or floor mount stands. Control panels and electrical equipment for manufacturing lines need rack mounting solutions that are configurable for the specific equipment layout.
Standard instrument stands
TechLine stock instrument stands in hot-dipped galvanized for standard manufacturing environments. Aluminum and stainless steel available for corrosive or high-cleanliness applications. Single, double, and triple horn mounts. Pipe mount, floor mount, wall mount, beam mount, and grating mount configurations. Stock ships within 24 hours.
ModRack for manufacturing line equipment
Manufacturing lines frequently mount multiple junction boxes, I/O panels, and control equipment along the production line. TechLine ModRack provides a configurable, field-assembled mounting solution that accommodates the varied equipment mix of a manufacturing line without requiring custom fabrication. The adjustable receiver system handles single strut, double strut, and 2" square tubing — covering virtually all panel and enclosure mounting applications.
OEM and skid applications — FixedRack
For OEM equipment builders who supply complete packaged systems with integrated electrical and instrument infrastructure, TechLine FixedRack custom welded racks provide a complete mounting solution built to the OEM's drawings. Any quantity from one to hundreds. Ships pre-assembled. Available in any finish.
SPECIALTY MANUFACTURING APPLICATIONS
Specific requirements for food, pharma, and chemical manufacturing.
Food and beverage processing
Cable management in food processing environments must resist wash-down chemicals, prevent bacterial harborage, and comply with applicable food safety regulations. Aluminum Snap Track is wash-down compatible and does not create the bacterial harborage risk of open wire basket's grid structure. For severe wash-down environments, 316SS Snap Track is available. Instrument stands in 316SS are standard for wet food processing areas.
Pharmaceutical manufacturing
Pharmaceutical facilities follow 21 CFR Part 211 and similar regulations that govern equipment and facility design for drug manufacturing environments. Cable management in pharmaceutical manufacturing areas must be cleanable, must not shed particles, and must be compatible with the cleaning and sanitization procedures used in the facility. Snap Track's solid side rails and ventilated aluminum bottom are compatible with pharmaceutical cleanroom requirements in a way that open wire basket is not.
Chemical manufacturing
Chemical manufacturing presents the same corrosion challenges as petrochemical processing, with the added variable of the specific chemicals being produced. For chemical manufacturing cable tray applications, material selection follows the same logic as oil and gas — aluminum for atmospheric corrosion, 316SS for chemical exposure — with the specific chemical compatibility verified against the process chemicals in use.
EPC AND EQUIPMENT PACKAGERS
Supporting EPC contractors and OEM equipment builders.
TechLine Mfg. has structured its operations to support both large EPC projects and smaller OEM equipment builders who need reliable, fast-shipping instrument support hardware.
For EPC contractors
Bulk quantities of standard Snap Track, instrument stands, and condensate chambers from stock. Dedicated project support for large orders. On-site installation training included with Snap Track project purchases. La Porte, Texas regional service center for Gulf Coast projects.
For OEM equipment builders
Small to medium quantity orders from stock with fast ship times. FixedRack custom fabrication for OEM skid mounting structures in any quantity. Consistent product availability that lets OEM builders maintain standard bill of materials across multiple builds of the same equipment package.
